Tip: Using Dline for Mechanical Ductwork… While you're in the Tool Properties dialog box, you may want to change the Name of the button and perhaps add an image.
Under the General section, change the Layer property to the desired layer, then set the Color and Linetype properties to ByLayer. Right justified based upon the direction of "travel" as you're picking each point of the Dline. The Dragline option which enables you to specify the Justification of the wall. Presses Enter it's easier to discern a semi-colon than a space when pressing Enter in a macro. ^C^CDLINE W 6 D R Text Character Reference In the example, I have the width set to 6″ as a sample wall width, but you can put whatever value you want in there as shown in my example below for ductwork. Edit the Command String to read as shown below. Right-click on the blank button, then click Properties to open the Tool Properties dialog box. Open the Tool Palette window, then you will need a blank button to work with (see Odd Spot, April 2007). Instructions to Add Properties to a Button for Creating a Dline #Inserting pdf into autocad 2003 download
For more on this wonderful little tool, take a look at August 2003 (where you can also download Dline.lsp) and the Odd Spot in September 2005. This month we'll put the Dline routine on a button with a pre-assigned Width for creating a wall, justification (Dragline option) and Layer. Top of page Power Tool Custom Button #6: Double-Line
#Inserting pdf into autocad 2003 how to
Note: For a review of how to add an Alignment Parameter, see the Power Tool, November 2005. Click your dynamic block, then click the visibility parameter icon to see the list… including the new block!
Click Close Block Editor and save the changes. Note: It would be a good idea to cycle through the other visibility states, just to make sure their states are properly configured. To isolate the new block from the one that was already there, click Make Invisible, then click the block that had been there (to make it invisible), leaving the new block associated with its visibility state in the drop-down list. Now that you have inserted the new one, you probably see two. When you opened the Block Editor in Step 1, one of the blocks is visible, of course. (It doesn't have to be the name of the block itself, but it's more intuitive if you do.) To add a new visibility state (for the new block), click Manage Visibility States, then click New and add the name you want to use for the new block, then click OK. Be sure to insert the block at the same insertion point as the other blocks. In this exercise, I insert the new block I created named "Quad".
Set the appropriate layer (the layer on which you want to insert the block), then launch the Insert command and insert the new block you want to include. After creating another block you want to add to the dynamic block, double-click the dynamic block to open the Edit Block Definition dialog box, then click OK to go into the Block Editor environment. Instructions to Include Another Block as a Visibility Parameter In the exercise, I add a Quad receptacle to an existing dynamic block. The following presumes you have a dynamic block with multiple visibility parameters and have made another block to add to it. The question comes when you need to pile on and add another block to the currently defined dynamic block. OK, that's the Reader's Digest version, but it really is that simple (see Michael's Corner, July 2006). All that's required is to make more than one block, place them on top of each other, then make a list and connect the right block to the right name. The result is essentially several blocks within one block.
The easiest dynamic block feature - for me - is the Visibility Parameter. Michael Adding Another Block as a Visibility Parameter If you would like to contact me directly, you can do that also. I hope these insights bump your productivity a bit today so you can have a few more minutes with your family or favorite activity. Both of those I thought were pretty slick and I hope you agree. Then one of my students was asking about bringing a PDF into AutoCAD, and when you think about it, it's nothing more than inserting it as an OLE object. I read an article in an eNewsletter that I subscribe to through Cadalyst which spoke about the Filters command that can be used to keep or delete layer filters you may encounter in a drawing you receive. The discoveries I wanted to pass along are those related to layer filters and PDF files. I'm also keeping the ball rolling with yet another custom button on the tool palette this one you can call "Wall Maker" or "Duct Worker" or whatever suits your particular application.
As you know, I'm passionate about palettes (professionally speaking), so I have finally gotten around to covering how to add another block as a visibility parameter on a dynamic block (which imminently ends up on a tool palette).
